Customized industrial coarse air filter 8 pocket G2 G4 M5 M6 F7 F8 F9 bag filter

Product Description

Bag filters are the most commonly-used air filters in industrial and ventilation systems. For these filters, it is the trend for fiber filtering media to replace traditional fiber glass materials.
Henan TOP Environmantal Production Equipment Co. , Ltd. adopts high-quality fiber filtering media to produce bag filters. The filtering grades include G3,G4,M5, M6,F7 and F8.

Technical Parameters

Efficiency	Material colar	Application
95%	Yellow	Electronic factories,National defense industry,sterile room,sterile plant
85%	Pink	Petro-chemical industry,plastic industry,pharmacy industry,food industry,coating factory,electronic factory,hospitals,labs
65%	Green	Coating booth,schools,and computer rooms.
45%	Orange	Commercial buildings,theaters,train stations.
35%	White	Pre-filter of a medium efficiency filter

Class	Size	Pocket no.	Filtration area(㎡）	Resistance/Airflow （Pa/m³/h)
G3	592×592×350	6	2.44	25/2500	40/3600	75/5000
G3	287×592×350	3	1.22	25/1250	40/1800	75/2500
G3	490×592×350	5	2.03	25/2000	40/3000	75/4000
G3	897×592×350	9	3.65	25/3750	40/5400	75/7500
G4	592×592×350	6	2.44	35/2500	60/3600	110/5000
G4	287×592×350	3	1.22	35/1250	60/1800	110/2500
G4	490×592×350	5	2.03	35/2000	60/3000	110/4000
G4	897×592×350	9	3.65	35/3750	60/5400	110/7500

Class	Diamensions	Pocket no.	Net Media (㎡）	Resistance(Pa)	Airflow(m³/h)
M5	592×592×600 592×592×500 287×592×600 287×592×500 490×592×600 490×592×500	3/4/5/6/8	1.93-6.18	20/25/40/45/70	1250/1800/2000/2500/3600/4000/5000
M6	592×592×650 592×592×550 287×592×650 287×592×550 490×592×650 490×592×550	4/5/6/8/10	2.79-8.06	35/40/60/65/75/100/110/125	1250/1800/2000/2500/3000/3600/4000/5000
F7	592×592×650 592×592×550 287×592×650 287×592×550 490×592×650 490×592×550	4/5/6/8/10	2.79-8.06	45/50/70/75/80/120/125	1250/1800/2000/2500/3000/3600/4000/5000
F8	592×592×650 592×592×550 287×592×650 287×592×550 490×592×650 490×592×550	4/5/6/8/10/12	2.27-9.44	60/65/70/100/105/110/170/175	1250/1800/2000/2500/3000/3600/4000/5000
