replacement MP filter
Pleated paper filter
OIL FILTER
MF1002P10NBP01
Oil Filter cartridge
replacement MP filter
Pleated paper filter
OIL FILTER
MF1002P10NBP01
Oil Filter cartridge

MP MF1002P10NBP01

Filtration accuracy:
1 ~ 100μm
Working pressure (MAX):
21bar-210bar
Working medium:
general hydraulic, phosphoric acid hydraulic oil, emulsion, water - glycol
Share:
Product Description
The filter is made of high quality glass fiber, oil filter paper, stainless steel, sinter felt filter material and other materials.Filter precision: from 1, 3, 6, 12, 25......
Microns.Pressure: 1.0Mpa, 2.0Mpa, 16.0Mpa, mainly used in hydraulic and lubrication systems, used to filter out the solid particles and colliform substances in the working medium and other pollutants, effectively control the pollution degree of the working medium, to ensure the normal operation of the system.
Technical Parameters
Filtration accuracy: 1 ~ 100μm
Working pressure (MAX) : 21bar-210bar
Working medium: general hydraulic, phosphoric acid hydraulic oil, emulsion, water - glycol
Operating temperature: -30℃ ~ +110℃
Medium: general hydraulic oil phosphoric acid hydraulic oil emulsion water - hexadiol
Sealing material: fluorine rubber ring butaniline gum.
Material quality: glass fiber filter paper -BN stainless steel woven mesh -W wood pulp filter paper -P stainless steel sintered mesh -V filtration accuracy: 1μ ~ 100
Advantages
01
Good filtration performance, 2-200um filter particle size can play a uniform surface filtration performance
02
Good corrosion resistance, heat resistance, pressure resistance and wear resistance
03
Flter hole uniform, accurate filtration accuracy
04
Filter is suitable for all kinds of hydraulic environment



MODEL:
MR2504A10A HP1352D16AN 8HP1352D16RN CS-150-P25-A MR2504A10A SF250M25 FRTE100P10S10
MF1001A025HBP01 MPF4001VG1 MF4001A25HV MF4002A25HB MF1001A025HBP01 MF4003P25HB HP1351A10AH
