Chinese manufacturer TOPEP hot sale bag filter housing for water purification

FRP Bag Filter Housing

Product Description

FRP filters include FRP PP melt-blown filters, FRP bag filters, FRP large-flow filter element filters and combined filters. Applicable to various types of PP melt-blown filter elements, #1 and #2 filter bags, PALL/PAKER/3M and other pleated filter elements. They have a series of advantages such as strong corrosion resistance, easy disassembly and assembly, and long service life.
It is widely used in the filtration of drinking water, industrial water and oil, and is particularly suitable for water conditions with high chloride ion content, high pH and strong corrosiveness. When traditional metal shell filters cannot be used, FRP can be selected.

Technical Parameters

Top Pressure	0.8Mpa
Using Temperature	5-66℃
Capacity	10-210t/h

Attention
a. Install the filter element in place and tighten the nut of the fixed sealing block
b. The working pressure cannot exceed the rated range
c. Open the exhaust valve before starting the machine, and close the exhaust valve as soon as possible after the air is exhausted
d. When the pressure difference exceeds the rated range, replace the filter material in time

Advantages

The housing body adopts FRP winding technology, which is corrosion-resistant, high-pressure-resistant and leak-resistant.

The spare parts are molded of fiberglass die-casting, resistant to high pressure, corrosion and leakage

Easy to install, opened by manual lifting ring, no tools are required when installing and replacing the filter element

There is a structure guide inside to align the filter automatically in installation, easy and convenient. The surface is coated with paint beautiful and elegant, environmental material, several colors for choice
